This series of 6300 high speed bearings is mainly used in the following fields: motor bearings for electric drills, high speed rotating bearings for saw blades, impeller bearings for small water pumps, conveyor roller bearings, agricultural machinery and other general machinery fields. It is one of the most commonly used bearing series in industrial transmissions.
|
Model |
6300 Series Deep Groove Ball Bearings |
|
Material |
GcR15,SUS420, SUS440,SUS304,SUS316 |
|
Dust cover |
ZZ, 2-RS,Open |
|
Accuracy |
ABEC7,ABEC5 |
|
Delivery time |
5-10 Days |
|
Advantage |
We are direct factory, offering OEM ODM custom service, the most favor price and best quality is guaranteed |
The 6300 series bearings produced by BLH Bearing Factory are a common deep groove ball bearing. Our mature manufacturing process results in low production costs, offering a high cost performance ratio. The bearings are dimensionally compatible and can replace the same model from major brands on the market. Installation and use are simple, and maintenance is low. These 6300 series bearings are the most common type in industrial transmission applications. Below is a table of bearing specifications for the 6300 series. As a leading bearing manufacturer, we offer a comprehensive range of models and can customize them to meet specific operating conditions and environments. For more technical information on our bearings, please contact us. We will provide comprehensive, one-stop service for your transmission needs.
bearing 6300 series parameter table
|
Bearing No. |
Bore |
O.D. |
Width |
Chamfer |
Load Rating |
Ball Complement |
Maxrunout speed |
Weight |
||||||
|
d |
D |
B |
r/min |
Dynamic |
Static |
No. |
Size |
Grease |
Oil |
kg |
||||
|
mm in |
mm in |
mm In |
mm |
Cr |
Cor |
mm |
r/min |
r/min |
||||||
|
633bearing |
3 |
0.11811 |
13 |
0.51181 |
5 |
0.19685 |
0.2 |
0.13 |
0.49 |
6 |
2.381 |
44000 |
54000 |
3.2 |
|
bearing634zz |
4 |
0.15748 |
14 |
0.62992 |
5 |
0.19685 |
0.3 |
0.135 |
0.52 |
8 |
2.36 |
40000 |
49000 |
5.1 |
|
bearing635zz |
5 |
0.19685 |
19 |
0.74803 |
6 |
0.2362 |
0.3 |
2.01 |
1.05 |
7 |
3.5 |
28000 |
36000 |
0.008 |
|
bearing636zz |
6 |
0.23622 |
22 |
0.86614 |
7 |
0.2756 |
0.3 |
2.5 |
1.5 |
7 |
3.969 |
25000 |
32000 |
0.009 |
|
bearing638rs |
8 |
0.31496 |
28 |
1.10236 |
9 |
0.3543 |
0.3 |
3.52 |
1.95 |
7 |
4.763 |
22000 |
30000 |
0.029 |
|
bearing6300zz |
10 |
0.3937 |
35 |
1.37795 |
11 |
0.4331 |
0.6 |
5.88 |
3.47 |
7 |
6.35 |
18000 |
24000 |
0.0532 |
|
bearing6301zz |
12 |
0.47244 |
37 |
1.45669 |
12 |
0.4724 |
1.0 |
7.48 |
4.65 |
6 |
7.938 |
17000 |
22000 |
0.0574 |
|
bearing6302rs |
15 |
0.59055 |
42 |
1.65354 |
13 |
0.5118 |
1.0 |
8.8 |
5.43 |
7 |
7.938 |
16000 |
20000 |
0.0804 |
|
bearing6303zz |
17 |
0.66929 |
47 |
1.85039 |
14 |
0.5512 |
1.0 |
10.45 |
6.56 |
7 |
8.731 |
15000 |
19000 |
0.1096 |
|
bearing6304rs |
20 |
0.7874 |
52 |
2.04724 |
15 |
0.5906 |
1.1 |
12.26 |
7.81 |
7 |
9.525 |
14000 |
17000 |
0.1417 |
|
bearing 6305zz |
25 |
0.98425 |
62 |
2.44094 |
17 |
0.6693 |
1.1 |
17.22 |
11.39 |
7 |
11.5 |
12000 |
14000 |
0.2193 |
|
bearing6306rs |
30 |
1.1811 |
72 |
2.83465 |
19 |
0.748 |
1.1 |
20.77 |
14.17 |
8 |
12 |
10000 |
12000 |
0.3498 |
|
bearing6307zz |
35 |
1.37795 |
80 |
3.14961 |
21 |
0.8268 |
1.5 |
33.2 |
19.2 |
8 |
13.494 |
5600 |
10000 |
0.4 |
|
bearing6308rs |
40 |
1.5748 |
90 |
3.54331 |
23 |
0.9055 |
1.5 |
40.8 |
24 |
8 |
15.081 |
5000 |
9000 |
0.42 |
|
bearing6309zz |
45 |
1.77165 |
100 |
3.93701 |
25 |
0.9843 |
1.5 |
52.8 |
31.8 |
8 |
17.462 |
4500 |
8000 |
0.83 |
S6300RS Bearing Assembly Video
This bearing utilizes Japanese SB-M high-temperature grease for uniform filling, making it maintenance-free. Dustproof grooves on the inner and outer rings provide excellent sealing, ensuring long-term operation in challenging environments. The 6300 series bearings include models 633-638 and 6300-6310. These models share the same manufacturing process, and the dustproof cover is available in either RS or ZZ options. We maintain a large inventory of all models, ensuring high quality, fast delivery, and competitive pricing.
